Hazardous goods storage container for water hazardous media, cold-insulated external HxWxD 2585 x 5075 x 4200 mm
zinc plated
- For frost-free, regulation compliant, versatile and mobile outdoor storage of temperature sensitive hazardous goods
- Thermally insulated containers protect valuable media against the effects of frost and low temperatures
- Approved for water hazardous liquids in GHS categories 1 – 4
- The inside of all walls, doors and the roof are insulated with 60 mm thick, non-flammable insulation material
- Heated with non-explosion-protected electric heater
- Robust, zinc plated steel construction
- Can be moved at any time when empty – crane eyelets, forklift access
- With double doors as standard
- Hot dip galvanised sump tray with grate, max. load 1000 kg/m² with evenly distributed load
- Can be used as small container storage in conjunction with shelving (accessory)
Non-icing and condensation free
For water hazardous liquids
Ref.: 523499 10
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery
- Fast delivery
We will be happy to help you
1 800 677 300
Monday-Friday 8am-5pm
Product description
For frost-free storage of water hazardous media in GHS categories 1 – 4
With convection heater (not explosion protected), factory fitted, wired to exterior mounted switch box, 230 V.
Zinc plated, particularly stable, profiled wall and roof panels made of sheet steel.
Reinforced roof and floor frame profiles, all round drainage rails (except for doors).
Weather protected ventilation openings in the doors and rear wall.
Double doors
With security lock.
Options available at extra cost
Insulated sump tray.
Exterior paintwork in sky blue RAL 5015.
Snow load: 150 kg/m²
EN 1055 compliant.
With convection heater (not explosion protected), factory fitted, wired to exterior mounted switch box, 230 V.
Zinc plated, particularly stable, profiled wall and roof panels made of sheet steel.
Reinforced roof and floor frame profiles, all round drainage rails (except for doors).
Weather protected ventilation openings in the doors and rear wall.
Double doors
With security lock.
Options available at extra cost
Insulated sump tray.
Exterior paintwork in sky blue RAL 5015.
Snow load: 150 kg/m²
EN 1055 compliant.
Please enquire about additional models such as containers with air conditioning and fire protection containers.
Pre-assembled, final assembly by customer.
- For frost-free, regulation compliant, versatile and mobile outdoor storage of temperature sensitive hazardous goods
- Thermally insulated containers protect valuable media against the effects of frost and low temperatures
- Approved for water hazardous liquids in GHS categories 1 – 4
- The inside of all walls, doors and the roof are insulated with 60 mm thick, non-flammable insulation material
- Heated with non-explosion-protected electric heater
- Robust, zinc plated steel construction
- Can be moved at any time when empty – crane eyelets, forklift access
- With double doors as standard
- Hot dip galvanised sump tray with grate, max. load 1000 kg/m² with evenly distributed load
- Can be used as small container storage in conjunction with shelving (accessory)
Non-icing and condensation free
For water hazardous liquids
Technical data
| External width | 5075 mm |
|---|---|
| External depth | 4200 mm |
| External height | 2585 mm |
| Place of use | outdoor use |
| Sump capacity | 2400 l |
| Position of double doors | long side |
| Heater type | convection heater (not explosion protected) |
| Internal height | 1910 mm |
| Internal width | 4840 mm |
| Internal depth | 3940 mm |
| Material | sheet steel |
| Finish | zinc plated |
| Door clearance width | 1950 mm |
| Door clearance height | 1900 mm |
| Max. snow load | 150 kg/m² |
| Door type | double hinged doors |
| For media | water hazardous dangerous goods |
| Type of floor | hot dip galvanised sump tray with grate, max. load 1000 kg/m² with evenly distributed load |
| Storage | frost-free |
| Heat output | 3 kW |
| Colour | zinc plated |
| Hazard class | for water hazardous liquids in GHS categories 1 – 4 |
| Test symbol | with general certification from the DIBt (German Institute for Construction Technology) Berlin |
| Lock type | security lock |
| Product type | cold insulated hazardous goods containers |
| Supplied | pre-assembled, final assembly by customer |
| Weight | 2750 kg |
| Instructions |
