Ref.: 977718 10
Scissor lift platform truck – eurokraft pro max. load 200 kg, manual lifting
lifting range 340 – 825 mm, solid rubber tyres
Ref.: 977718 10
Scissor lift platform truck – eurokraft pro max. load 200 kg, manual lifting
lifting range 340 – 825 mm, solid rubber tyres
lifting range 340 – 825 mm, solid rubber tyres
€ 2,750.00
Price / item (Excl. VAT)
Delivery time: 7-8 Week Delivery
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery from Germany
- Fast delivery
We will be happy to help you
1 800 677 300
Monday-Friday 8am-5pm
Do you have any questions about this product?€ 2,750.00
Price / item (Excl. VAT)
Product description
- Manual lifting
- For lifting and positioning heavy components
- Solid rubber tyres impact resistant, vibration damping, also for uneven floors
- Ergonomic working height for assembly and maintenance
- Powerful hydraulic cylinder with bio oil
- Zinc plated platform, powder coated frame
- Quality product – Made in Germany
The eurokraft pro scissor lift platform truck is suitable for lifting and positioning heavy components and tools. As a versatile work platform, it ensures you have the right working height, especially for assembly and maintenance work, enables ergonomic work and positions the component exactly where it is needed.
The scissor lift platform truck with manual lifting and a max. load of 200 kg is equipped with a hydraulic lifting cylinder with bio oil. This allows loads to be raised to the appropriate working height with little effort using the foot pedal. Another pedal enables gentle load lowering. The foot pedal folds in to prevents it from protruding into the work area. The solid rubber tyres are non-marking and vibration damping, which also makes them particularly suitable for uneven floors. Two swivel castors with double stops make the lift platform truck highly manoeuvrable, as well as stable when the device is used at the work site.
The scissor lift platform truck with manual lifting and a max. load of 200 kg is equipped with a hydraulic lifting cylinder with bio oil. This allows loads to be raised to the appropriate working height with little effort using the foot pedal. Another pedal enables gentle load lowering. The foot pedal folds in to prevents it from protruding into the work area. The solid rubber tyres are non-marking and vibration damping, which also makes them particularly suitable for uneven floors. Two swivel castors with double stops make the lift platform truck highly manoeuvrable, as well as stable when the device is used at the work site.
The zinc plated platform provides corrosion protection and durability, while the frame and push handle are powder coated and therefore designed for demanding everyday use. Even when subject to intensive two shift use, stability and performance are maintained over the long term. The scissor lift platform truck therefore provides support when setting up for work and positioning heavy components in industry and workshops.
Drawbar not mounted on delivery – easy self-assembly.
10 year guarantee
Technical data
| Max. load | 200 kg |
|---|---|
| Lifting range | 340 – 825 mm |
| Wheel material | solid rubber |
| Feature | mobile manual |
| Platform length | 915 mm |
| Platform width | 600 mm |
| Length | 1225 mm |
| Width | 630 mm |
| Platform material | steel, zinc plated |
| Push handle version | bolted on |
| Lift per pedal stroke | 15 mm |
| Frame colour | light blue RAL 5012 |
| Frame material | steel, powder coated |
| Lift drive | pedal hydraulics |
| Wheel fittings | 2 steering wheels with double stops, 2 fixed wheels |
| Wheel diameter | 100 / 160 mm |
| Wheel bearing | ball bearing |
| Weight | 63 kg |
| Fittings | push handle |
| Product type | lifting platform trolleys |
| Supplied | assembled |
| Instructions | |
| Manufacturer / EU responsible Person (GPSR) |
Sustainability
Sustainable product
This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.
You can find out more about product evaluation and our sustainability initiative on our information page .
This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.
You can find out more about product evaluation and our sustainability initiative on our information page .
Product CO₂ footprint
- Product Carbon Footprint per kg CO2e
- 351.674
- Product Carbon Footprint Calculation Year
- 2026
- Product Carbon Footprint System Boundaries
- Cradle-to-gate
- Product Carbon Footprint Calculation Method
- Calculated by our partner GlobalChanger (GreenZero) in accordance with ISO 14044 (LCA) / 14067 (PCF) (GWP100 [IPCC version]) principles.<br/>PCF values are product specific averages that have not been verified by third parties and may evolve as the data basis improves.
| Criteria | Weighting | Score |
|---|---|---|
| 30% | 3.5 | |
| 30% | 2.0 | |
| 25% | 1.0 | |
| 10% | 5.0 | |
| 5% | 3.5 | |
| Overall score | 3.1 | |
