Ref.: 854559 10

Electric drum pump – basic model – Lutz for solvents, explosion protected

Electric drum pump – basic model – Lutz
Basic model – pump without accessories

without accessories

€ 3,275.00
Price / item (Excl. VAT)
Delivery time: 6-8 Working Days
Product description
  • For solvents (explosion protected)
  • Ergonomically designed motor housing with an on/off switch that is easy to operate
  • Safe pumping of water hazardous, corrosive and flammable liquids
  • Pump unit constructed without seals for operation even if the pump runs dry temporarily
  • Suitable pumps for all types of liquids
For flammable hydrocarbons such as ethanol, petrol, butanol, isopropanol, kerosene, methanol, petroleum etc.
For corrosive media or unspecified media, please enquire about compatibility beforehand.
Supplied flat pack – easy self-assembly.
The max. pump rate is a value determined by means of a test bench, measured with water as the medium at a temperature of approx. 20 °C. The measurement is made at the outlet port of the pump, without a hose, nozzle or flow meter. The pump rate that can be attained in use is lower, and depends on the individual job, the properties of the pumped medium and the configuration of the pump. The max. pumping height also depends on the pump design, motor and medium. The viscosity values are determined using oil.
Technical data
Design of pumpfor drums
For mediasolvents (explosion protected)
Scope of deliverybasic appliance
For liquidsflammable hydrocarbons, such as ethanol, petrol, butanol, isopropanol, kerosene, methanol, petroleum
Material of pumpNiRo (stainless steel)
Drive shaft materialNiRo (stainless steel)
Immersion depth1000 mm
Pump rate95 l/min
Pumping height14 m wc
Featureexplosion protected
Power430 watt
Weight0 kg
Colourblack silver
Product typedrum pumps, electric
Suppliedassembled
