Ref.: 487019 10
Step shelf ladder – KRAUSE with wheels on top for round tubing rail system
7 steps
Number of steps [pcs.]
Ref.: 487019 10
Step shelf ladder – KRAUSE with wheels on top for round tubing rail system
7 steps
7 steps
10 year guarantee
Sustainability score:Number of steps [pcs.]
€ 515.00
Price / item (Excl. VAT)
Delivery time: up to 4 weeks
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery from Germany
- Fast delivery
€ 515.00
Price / item (Excl. VAT)
€ 515.00
Price / item (Excl. VAT)
Delivery time: up to 4 weeks
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery from Germany
- Fast delivery
Product description
- High stability due to high strength beaded step-rail connection
- Safe ascent due to 80 mm deep, profiled steps
- Space saving suspension when not in use
This step shelf ladder is the optimal supplement to every shelf system. In combination with a round tubing rail system (tubing diameter 30 mm), this lean to ladder provides fast and safe access to shelves located at a height. 2 self locking braked castors (diameter 80 mm) ensure it is easy to move. The two component ladder feet provide a sturdy footing during use. The ladder inclination totals 21°. When work is finished, the ladder can be placed vertically against the shelf to save space – in the parking position.
The vertical suspension height is decisive to selecting the right shelf ladder (distance from the ground to the lower edge of the rail system).
Round tubing rail system, handrail and holding rod are available as accessories.
The vertical suspension height is decisive to selecting the right shelf ladder (distance from the ground to the lower edge of the rail system).
Round tubing rail system, handrail and holding rod are available as accessories.
Technical data
| Access type | steps |
|---|---|
| Width | 570 mm |
| Max. load | 150 kg |
| Frame material | aluminium |
| Material of treads | aluminium |
| Step depth | 80 mm |
| Feature | mobile |
| Colour | aluminium silver |
| Product type | shelf ladders |
| Supplied | assembled |
| Number of steps | 7 pcs. |
| Vertical hook-in height | 2150 mm |
| Standing height | 900 mm |
| Length | 1950 mm |
| Working height | 2900 mm |
| Weight | 9.2 kg |
| Manufacturer / EU responsible Person (GPSR) |
Sustainability
Sustainable product
This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.
You can find out more about product evaluation and our sustainability initiative on our information page .
This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.
You can find out more about product evaluation and our sustainability initiative on our information page .
Product CO₂ footprint
- LCA functional unit
- 1
- Recycled content in %?
- 61
- CO2 footprint year of calculation
- 2026
- LCA validity (in years)
- 1
- CO2 footprint calculation method product
- Calculated by our partner GlobalChanger (GreenZero) in accordance with ISO 14044 (LCA) / 14067 (PCF) (GWP100 [IPCC version]) principles.<br/>PCF values are product specific averages that have not been verified by third parties and may evolve as the data basis improves.
- CO2 footprint system boundaries
- Cradle-to-gate
PCF Lifecycle Breakdown
PCF Lifecycle Breakdown68.08kg CO₂e
| LCA Raw Material Extraction & Processing | 62% |
| LCA packaging production | 1.1% |
| LCA Product Manufacturing | 31.7% |
| LCA Inbound and Outbound Transportation | 5.2% |
Scoring System
More about our sustainability approach.
3.2/5.9Overall score
| Criteria | Weighting | Score |
|---|---|---|
 Climate protection | 30% | 2.5 |
 Circulatory economy | 30% | 4.6 |
 Biodiversity | 25% | 2.0 |
 Economic efficiency | 10% | 3.0 |
 Innovation | 5% | 3.9 |
