Ref.: 568383 10

TPE tyres on PP rim, ESD, 2+ items wheel Ø x width 100 x 32 mm

TPE tyres on PP rim, ESD, 2+ items

fixed castor

Structure
€ 26.90
Price / item (Excl. VAT)
€ 53.80
Total (Excl. VAT)
Delivery time: 9-11 Working Days
Product description
  • ESD model
  • Do not damage floors, non-marking
  • Low rolling resistance, quiet, very smooth running
  • Hardness 65 – 70 Shore A
  • Temperature resistant from –20 °C to +60 °C
With an electrical conductivity up to a resistance of 0 – 5,000,000 ohm.
Sheet steel housing, electrolytically zinc plated in blue. Swivel bearing with dual turntable bearing. Small plastic thread guard. Ball bearings.
TPE wheels may leave oily marks on open-pored, unsealed and absorbent flooring.
We are happy to advise you about use on parquetry, stone or other sensitive flooring.
Anti-static
This symbol indicates that the product is a conductive version (in relation to electricity or static charges).
Anti-static. This symbol indicates that the product is a conductive version (in relation to electricity or static charges).
Low rolling resistance
Low rolling resistance
Non-marking
Non-marking
Technical data
Wheel diameter100 mm
Wheel materialrubber – thermoplastic rubber elastomer (TPE)
Material of rimpolypropylene
Type of mountingwith top plate
Housing materialsteel
Max. load at 4 km/h90 kg
Wheel width32 mm
Overall height125 mm
Wheel bearingball bearing
Temperature resistance–20 °C to +60 °C
Swivel castor offset40 mm
Screw hole diameter8 mm
Hub length40 mm
Hub bore8 mm
Fixed castor plate dimensions105 x 80 mm
Swivel castor plate dimensions105 x 80 mm
Screw hole spacing80/77 x 60 mm
Housing surfacezinc plated by galvanization
Shore hardness65 – 70
Suppliedassembled
Structurefixed castor
Product typefixed castors
Weight0.467 kg
