Ref.: 984845 10
Steel sump tray – eurokraft pro LxWxH 800 x 1300 x 205 mm
painted fir green RAL 6011, with grate
Type of grate
Sump capacity [l]
Drum capacity
Width [mm]
Height [mm]
Colour
Ref.: 984845 10
Steel sump tray – eurokraft pro LxWxH 800 x 1300 x 205 mm
painted fir green RAL 6011, with grate
painted fir green RAL 6011, with grate
10 year guarantee
For water hazardous liquids
For flammable liquids
Sustainability score:Type of grate
Sump capacity [l]
Drum capacity
Width [mm]
Height [mm]
Colour
€ 419.00
Price / item (Excl. VAT)
Delivery time: up to 4 weeks
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery from Germany
- Fast delivery
€ 419.00
Price / item (Excl. VAT)
€ 419.00
Price / item (Excl. VAT)
Delivery time: up to 4 weeks
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery from Germany
- Fast delivery
Product description
- For regulation compliant storage and filling
- For 60 litre drums and small containers
- With ÜHP declaration of conformity according to StawaR
- Approved for flammable liquids in GHS categories 1 – 3
- Approved for water-hazardous liquids in GHS categories 1 – 4
Steel sump tray for safe hazardous substance storage
The steel sump tray combines robust materials with tested safety and creates a reliable basis for the compliant storage and dispensing of liquids. The sturdy model made of painted 3 mm sheet steel is particularly suitable for use in demanding operational environments.
As a resistant steel tray, the product reliably collects leaking liquids and protects work areas, floors and the environment from contamination. The sump tray is equipped with sturdy support feet and designed for a max. load of 1,000 kg/m². This allows 60-litre drums and smaller containers to be positioned and handled safely.
The ground clearance of 100 mm facilitates internal transport. As the steel tray can be driven under from all four sides, it can be flexibly picked up and positioned using suitable lifting equipment. This supports efficient warehouse organisation and facilitates adaptation to changing operational processes.
The tray with a declaration of conformity (ÜHP) in accordance with StawaR is approved for flammable liquids of GHS categories 1 to 3. In addition, it is suitable for liquids hazardous to water of GHS categories 1 to 4. As a result, the steel tray provides a reliable basis for the safe storage of relevant hazardous substances.
The painted surface supports the longevity of the sump tray and facilitates inspection for contamination or leaked liquids. Support feet provide additional clearance from the floor and improve accessibility during cleaning and inspection.
This product is ideal for the compliant storage and dispensing of hazardous substances in drums and small containers.
The steel sump tray combines robust materials with tested safety and creates a reliable basis for the compliant storage and dispensing of liquids. The sturdy model made of painted 3 mm sheet steel is particularly suitable for use in demanding operational environments.
As a resistant steel tray, the product reliably collects leaking liquids and protects work areas, floors and the environment from contamination. The sump tray is equipped with sturdy support feet and designed for a max. load of 1,000 kg/m². This allows 60-litre drums and smaller containers to be positioned and handled safely.
The ground clearance of 100 mm facilitates internal transport. As the steel tray can be driven under from all four sides, it can be flexibly picked up and positioned using suitable lifting equipment. This supports efficient warehouse organisation and facilitates adaptation to changing operational processes.
The tray with a declaration of conformity (ÜHP) in accordance with StawaR is approved for flammable liquids of GHS categories 1 to 3. In addition, it is suitable for liquids hazardous to water of GHS categories 1 to 4. As a result, the steel tray provides a reliable basis for the safe storage of relevant hazardous substances.
The painted surface supports the longevity of the sump tray and facilitates inspection for contamination or leaked liquids. Support feet provide additional clearance from the floor and improve accessibility during cleaning and inspection.
This product is ideal for the compliant storage and dispensing of hazardous substances in drums and small containers.
Technical data
| Length | 800 mm |
|---|---|
| Material | sheet steel |
| Finish | painted |
| Max. load | 1000 kg/m² |
| Clearance height | 100 mm |
| Test symbol | manufacturers declaration of conformity in accordance with StawaR |
| Material thickness | 3 mm |
| For media | flammable and water hazardous liquids |
| Hazard class | for flammable liquids in GHS categories 1 – 3 as well as water hazardous liquids in GHS categories 1 – 4 |
| Distributed load | 1000 kg/m² |
| Certification | with |
| Product type | 60 l sump trays |
| Supplied | assembled |
| Type of grate | with zinc plated grate |
| Sump capacity | 63 l |
| Drum capacity | 6 x 60 l |
| Width | 1300 mm |
| Height | 205 mm |
| Colour | reseda green RAL 6011 |
| Weight | 60 kg |
| Manufacturer / EU responsible Person (GPSR) |
Sustainability
Sustainable product
This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.
You can find out more about product evaluation and our sustainability initiative on our information page .
This product actively contributes to protecting our environment and taking social responsibility. It meets our strict sustainability criteria and thus supports an economically, ecologically and socially viable future. The score asks the crucial question for every product: does this product contribute to creating sustainable and fair conditions for today and future generations? Below are the categories in which this product performs particularly well.
You can find out more about product evaluation and our sustainability initiative on our information page .
Product CO₂ footprint
- LCA functional unit
- 1
- Recycled content in %?
- 25
- CO2 footprint year of calculation
- 2026
- LCA validity (in years)
- 1
- CO2 footprint calculation method product
- Calculated by our partner GlobalChanger (GreenZero) in accordance with ISO 14044 (LCA) / 14067 (PCF) (GWP100 [IPCC version]) principles.<br/>PCF values are product specific averages that have not been verified by third parties and may evolve as the data basis improves.
- CO2 footprint system boundaries
- Cradle-to-gate
PCF Lifecycle Breakdown
PCF Lifecycle Breakdown292.15kg CO₂e
| LCA Raw Material Extraction & Processing | 45.8% |
| LCA packaging production | 1.6% |
| LCA Product Manufacturing | 44.7% |
| LCA Inbound and Outbound Transportation | 7.9% |
Scoring System
More about our sustainability approach.
3.7/5.9Overall score
| Criteria | Weighting | Score |
|---|---|---|
 Climate protection | 30% | 2.5 |
 Circulatory economy | 30% | 4.2 |
 Biodiversity | 25% | 3.0 |
 Economic efficiency | 10% | 3.0 |
 Innovation | 5% | 3.9 |
