Ref.: 523506 10
Hazardous goods storage container for flammable media, cold-insulated – LaCont external HxWxD 2585 x 5075 x 6300 mm
zinc plated
Ref.: 523506 10
Hazardous goods storage container for flammable media, cold-insulated – LaCont external HxWxD 2585 x 5075 x 6300 mm
zinc plated
zinc plated
€ 53,900.00
Price / item (Excl. VAT)
Delivery time: 9-10 Week Delivery
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery from Germany
- Fast delivery
We will be happy to help you
1 800 677 300
Monday-Friday 8am-5pm
Do you have any questions about this product?€ 53,900.00
Price / item (Excl. VAT)
Product description
- For frost-free, regulation compliant, versatile and mobile outdoor storage of temperature sensitive hazardous goods
- Thermally insulated containers protect valuable media against the effects of frost and low temperatures
- Approved for flammable liquids in GHS categories 1 – 3
- The inside of all walls, doors and the roof are insulated with 60 mm thick, non-flammable insulation material
- Heated with explosion protected electric heater
- Robust, zinc plated steel construction
- Can be moved at any time when empty – crane eyelets, forklift access
- With double doors as standard
- Hot dip galvanised sump tray with grate, max. load 1000 kg/m² with evenly distributed load
- Can be used as small container storage in conjunction with shelving (accessory)
For frost-free, active or passive storage of flammable media in GHS categories 1 – 3
For storing opened containers.
Approved for opening, filling and emptying of containers in storage.
With electric heater (T3 explosion protection), factory fitted and explosion protected forced ventilation to comply with regulatory 5-fold air exchange requirement.
Wired to exterior mounted switch box, 230 V.
Zinc plated, particularly stable, profiled wall and roof panels made of sheet steel.
Reinforced roof and floor frame profiles, all round drainage rails (except for doors).
Weather protected ventilation openings in the doors and rear wall.
Double doors
With security lock.
Options available at extra cost
Insulated sump tray.
Exterior paintwork in sky blue RAL 5015.
Fume monitoring device
– Monitors effectiveness of ventilation in accordance with TRGS 510
– Proscribed with at least twofold air exchange
– Including flow sensor with evaluation unit, equipotential bonding bar, alarm horn
Please order together with container, no retrofitting possible.
Snow load: 150 kg/m²
EN 1055 compliant.
For storing opened containers.
Approved for opening, filling and emptying of containers in storage.
With electric heater (T3 explosion protection), factory fitted and explosion protected forced ventilation to comply with regulatory 5-fold air exchange requirement.
Wired to exterior mounted switch box, 230 V.
Zinc plated, particularly stable, profiled wall and roof panels made of sheet steel.
Reinforced roof and floor frame profiles, all round drainage rails (except for doors).
Weather protected ventilation openings in the doors and rear wall.
Double doors
With security lock.
Options available at extra cost
Insulated sump tray.
Exterior paintwork in sky blue RAL 5015.
Fume monitoring device
– Monitors effectiveness of ventilation in accordance with TRGS 510
– Proscribed with at least twofold air exchange
– Including flow sensor with evaluation unit, equipotential bonding bar, alarm horn
Please order together with container, no retrofitting possible.
Snow load: 150 kg/m²
EN 1055 compliant.
Please enquire about additional models such as containers with air conditioning and fire protection containers.
Pre-assembled, final assembly by customer.
Non-icing and condensation free
For flammable liquids
Technical data
| Width | 5075 mm |
|---|---|
| Depth | 6300 mm |
| Height | 2585 mm |
| Place of use | outdoor use |
| Sump capacity | 3600 l |
| Position of hinged door | short side |
| Internal height | 1910 mm |
| Internal width | 4840 mm |
| Internal depth | 6040 mm |
| Material | sheet steel |
| Finish | zinc plated |
| Door clearance width | 1950 mm |
| Door clearance height | 1900 mm |
| Max. snow load | 150 kg/m² |
| Door type | double hinged doors |
| For media | flammable liquids |
| Type of floor | hot dip galvanised sump tray with grate, max. load 1000 kg/m² with evenly distributed load |
| Heat output | 2 x 3 kW |
| Colour | zinc plated |
| Hazard class | for flammable liquids in GHS categories 1 – 3 |
| Test symbol | with general certification from the DIBt (German Institute for Construction Technology) Berlin |
| Lock type | security lock |
| Product type | cold insulated hazardous goods containers |
| Supplied | pre-assembled, final assembly by customer |
| Weight | 4030 kg |
| Instructions |
