Ref.: 518953 10

Display case for indoor and outdoor use portrait format

Display case for indoor and outdoor use
Display case for indoor and outdoor use, portrait format, for A1, door opens 180° to the right-0
Display case for indoor and outdoor use (Product illustration 2)-1
Display case for indoor and outdoor use (Product illustration 3)-2

for A1, door opens 180° to the right

For format
€ 799.00
Price / item (Excl. VAT)
Delivery time: 9-11 Working Days
Product description
  • Weather resistant aluminium construction, brushed and silver anodised, rear panel optionally available in charcoal RAL 7016 or pure white RAL 9010 for indoor or outdoor use
  • Door convenient to open upwards by 90° using a gas spring, locks into place, or 180° to the side when in vertical format
  • Fire protection class B1, flame resistant – corners with bonded rubber seals for optimum weather resistance, with integrated ventilation and water drainage system
  • Patented, partially concealed hinge system – prevents magnets from falling between hinges when closing
  • Includes 10 grey magnets and one magnetic A4 document pouch
  • Extensive accessories also available
Rear panel made of zinc plated sheet steel. Glass pane made of 4 mm single pane safety glass. Common key cylinder locks, 2 keys per lock.
The stand is not included with delivery, see accessories.
Lighting, diverse accessories and other models, custom sizes, RAL colours and rear panel in gentian blue RAL 5010 available on request.
5 year guarantee
5 year guarantee
The product corresponds to fire protection construction requirements. It has been classified as highly non-flammable.
The product corresponds to fire protection construction requirements. It has been classified as highly non-flammable.
Technical data
Modelportrait
Depth80 mm
Internal depth45 mm
Design of display boxwith steel rear wall, for magnets
Materialsingle pane safety glass
Glass thickness4 mm
Frame materialanodised aluminium
Frame coloursilver
Panel materialsheet steel, galvanised
Panel colourcharcoal RAL 7016
Door opening180° to the right
Lock type2 cylinder locks, common key with 2 keys
Place of useindoor and outdoor use
Type of mountingwall mounting
Product typehinged door display cases
Suppliedassembled
For formatA1
Capacity A4 sheets9 (3 x 3) pcs.
Height1025 mm
Width800 mm
Viewable area height895 mm
Viewable area width670 mm
Weight20.5 kg
