Ref.: 969190 10
Elastic solid rubber tyre, grey – Proroll wheel Ø x width 160 x 50 mm
(1)
swivel castor
Structure
Ref.: 969190 10
Elastic solid rubber tyre, grey – Proroll wheel Ø x width 160 x 50 mm
(1)
swivel castor
swivel castor
Structure
€ 87.90
Price / item (Excl. VAT)
Only 16 available
Delivery time: 6-8 Working Days
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery from Germany
- Fast delivery
We will be happy to help you
1 800 677 300
Monday-Friday 8am-5pm
Do you have any questions about this product?€ 87.90
Price / item (Excl. VAT)
Product description
- On aluminium rim with non-marking tyres
- Low rolling resistance, quiet running
- Very smooth running, low rolling resistance
- Hardness 70 Shore A
- Temperature resistant from –20 °C to +70 °C
On request
For swivel castors without double stops. 1 x 360° directional stops can be retrofitted, turning the swivel castor into a fixed castor.
For swivel castors without double stops. 1 x 360° directional stops can be retrofitted, turning the swivel castor into a fixed castor.
Vulcanised running surface. Swivel bearing with double ball race, swivel bearing protection.
High maximum load
Low rolling resistance
Non-marking
Technical data
| Wheel diameter | 160 mm |
|---|---|
| Wheel material | rubber – solid rubber – full elastic |
| Material of rim | aluminium |
| Type of mounting | with top plate |
| Housing material | steel |
| Max. load at 4 km/h | 350 kg |
| Wheel width | 50 mm |
| Overall height | 190 mm |
| Wheel bearing | precision ball bearing |
| Temperature resistance | –20 °C to +70 °C |
| Swivel castor offset | 52 mm |
| Screw hole diameter | 11 mm |
| Hub length | 60 mm |
| Hub bore | 20 mm |
| Model | transport castors |
| Fixed castor plate dimensions | 135 x 110 mm |
| Swivel castor plate dimensions | 135 x 110 mm |
| Screw hole spacing | 105 x 80 mm |
| Housing surface | zinc plated |
| Shore hardness | 70 A |
| Feature | low rolling resistance does not damage floors non-marking |
| Supplied | assembled |
| Structure | swivel castor |
| Product type | swivel castors |
| Weight | 2.5 kg |
