Ref.: 611031 10
X-GUARD machine protective fencing, add-on door kit (without door panel element, uprights and locking mechanism) – Axelent double door as hinged door
HxW 2300 x max. 3000 mm
Height [mm]
Ref.: 611031 10
X-GUARD machine protective fencing, add-on door kit (without door panel element, uprights and locking mechanism) – Axelent double door as hinged door
HxW 2300 x max. 3000 mm
HxW 2300 x max. 3000 mm
Height [mm]
€ 429.00
Price / item (Excl. VAT)
Delivery time: 5-6 Week Delivery
Good reasons to purchase products from us
- Guarantee of up to 15 years
- 30 day right of return
- Free delivery from Germany
- Fast delivery
We will be happy to help you
1 800 677 300
Monday-Friday 8am-5pm
Do you have any questions about this product?€ 429.00
Price / item (Excl. VAT)
Product description
- X-GUARD – the protective fencing system for machines, systems, robots, storage and logistics – 200 mm safety clearance from source of danger
- Fulfils machine directive 2006/42/EC
- Regulation compliant mesh size of 30 x 50 mm – cannot be reached through
- High quality powder coating
- Add-on door kit converts wall sections into single/double hinged doors or sliding doors
- Quick and easy assembly
Hinged doors and sliding doors are available in single and double door versions. They are designed to enable versatile mounting options. At least one wall section and two uprights are required for the add-on door kits offered.
Please order together with the necessary X-GUARD CLASSIC wall sections and uprights.
Lock housing and handle (for the installation of a Euro lock cylinder provided by the customer) can be included with your order as an accessory. A Euro lock system cannot be fitted at a later stage.
Please order together with the necessary X-GUARD CLASSIC wall sections and uprights.
Lock housing and handle (for the installation of a Euro lock cylinder provided by the customer) can be included with your order as an accessory. A Euro lock system cannot be fitted at a later stage.
X-Lock system incl. suitable safety switch is available on request.
With mechanical splint which holds the doors open.
The mechanism requires intentional activation from outside to open and close doors.
From inside, X-Lock can always be opened, but never closed.
In accordance with EN ISO 12100, section 5.5.3.
With mechanical splint which holds the doors open.
The mechanism requires intentional activation from outside to open and close doors.
From inside, X-Lock can always be opened, but never closed.
In accordance with EN ISO 12100, section 5.5.3.
Important ordering information for add-on door kits
When ordering doors kits, the required X-GUARD CLASSIC door panels, uprights and the corresponding locking mechanism must be ordered at the same time.
When ordering doors kits, the required X-GUARD CLASSIC door panels, uprights and the corresponding locking mechanism must be ordered at the same time.
5 year guarantee
Technical data
| Width | 3000 mm |
|---|---|
| Door type | hinged door |
| Door hinge position | left or right |
| Model | double door |
| Finish | powder coated |
| Mesh size | 30 x 50 mm |
| Thickness of wire | 3.0 / 2.5 mm |
| Material | rectangular steel pipe steel wire |
| Frame profile | 20 x 30 mm |
| Lock type | without lock |
| Stiffening profile | 25 x 15 mm |
| Colour | graphite black RAL 9011 |
| Product type | machine protective fencing made of steel |
| Supplied | flat pack |
| Height | 2300 mm |
| Weight | 10.31 kg |
| Pictorial instructions |
