StandardClothes lockers made of steel DIN 4547, RAL-RG 614/6, manufactured in Germany.
Dimensions/tolerancesGeneral tolerances according to DIN ISO 2768-1 (mean)
MaterialCold rolled sheet steel DC 01 according to DIN EN 10130/10131, fully recyclable, long service life, maintenance free, excellent stability, easy care and hygienic. Thickness of sheet steel:
JoiningSpot welding, pressure joining
Surface finishPhosphate coated and stove enamelled, gloss level of 50 to 70 percent, the dry film bonding layer 20 - 25 micrometres. Oven dried, alkyd/melamine resin based wet paint finish, stoved for 15 minutes at 140 °C.
LocksNickel plated metal rotary bolt lock, with forked spring, for padlocks with a bar thickness of 6 - 7 mm, locking travel 180°.
VentilationStandard ventilation with 3 punched ventilation slots at the top and bottom of each door, cross section approx. 30 cm2, alternatively with hole pattern in the rear panel for solid panel doors. Perforated metal doors with two 35 mm wide perforated metal strips, 10 mm perforations, 7 mm spacing. Doors with square holes, 120 mm wide hole pattern, 20 x 20 mm holes, 5 mm spacing.
SafetyOur products bear the TÜV symbol (tested safety, monitored production) issued by TÜV Product Service or the appropriate UK ISO equivalent. We will gladly send you the required certificates on request.
Recommended cleaningFor lighter dirt, clean with a soft, damp cloth without additional cleaning agents. For stubborn dirt, same as above but add a small amount of neutral or slightly alkaline cleaning agent. Do not wash lockers with water, do not clean them with steam jet or with polishing, abrasive or solvent based cleaning agents.
