Pallet truck with QuickLift, max. load 2500 kg

fork length 1150 mm

Unfortunately this product is no longer available.

You can contact us on 1 800 677 300

LO_QUICKLIFT

LO_EUROKRAFT

Sturdy. Torsion resistant due to extremely strong, high quality steel profiles. Powder coated in light blue RAL 5012.

QuickLift is active for loads of up to 150 kg.

Nylon fork rollers
Very low drag, high resistance to chemicals, non-marking. Suitable for smooth, level floors.

Solid rubber tyres
Quiet running, extremely durable. Cannot be cut by metal chippings. Non-marking, ideal for smooth and rough floors.

Polyurethane fork rollers
For delicate floors, hardwearing, non-marking and impact absorbing. Quiet running.

Tandem rollers
Ideal for heavy loads. Suitable for uneven floors.

Product advantages
  • With QuickLift hydraulic unit - saves effort and time
  • Pump twice and the pallet is already off the ground
  • Pump four times and the maximum lifting height is attained


Product & Price Information








Ref.
614 517
614 518
614 519



Alternatives & Options


Technical data

Max. loadkg2500
Lifting range85 - 200 mm
Turning angle°210
Overall lengthmm1550
Fork lengthmm1150
Fork widthmm160
Loading widthmm540
Materialsteel
Finishpowder-coated
Colourlight blue RAL 5012
Steering wheel diametermm200
Fork roller diametermm82
Fork roller widthmm70
Fork roller versiontandem

Quality advantages

  • P_JAHR0068KK-en
